AOX-FQ Series Spring Rerurn Electric Valve Actuator
AOX-FQ Series Spring Rerurn Electric Valve Actuator
Regular price
$3,650.00 USD
Regular price
Sale price
$3,650.00 USD
Unit price
/
per
Couldn't load pickup availability
Ingress Protection: IP67 (IP68 optional), explosion-proof rating: Exdb ⅡC T5
Torque Range: 50-300Nm
Travel Range: 0-90°
Spring Return Time: Less than 3 seconds
Functional Modes: Intelligent (ICUC), non-invasive integrated (SRCU), regulating (PCU), switching
Communication Protocols: Modbus, Profibus, Hart
Operating Temperature: -30℃~+70℃ (optional: -30℃, -40℃, -60℃)
Product Introduction:
The AOX-FQ series is a reliable and efficient electric actuator designed for valves and dampers. Featuring a spring return mechanism, it ensures safe operation by automatically returning the actuator to a safe position in case of power failure.
Product Specifications:
| General specifications | |
| Torque range | 50-300Nm |
| Shell material | Die cast aluminum |
| Position indicator | Even in case of power failure, the valve position dial can display continuous position changes |
| Tightness | |
| External corrosion protection | Paint system |
| ·Polyester powder coating conforms to GBT 18593-2001 standard ·Optional protection for highly corrosive condition | |
| ·Screws are all stainless steel screws | |
| Travel/limit | |
| Trave | 90 ° standard (90 °~270 ° optional) |
| Power loss reset direction | Off, the opening direction can be set |
| Midway stop | Electromagnetic brake control |
| Limit mode | Electric control: electronic limit |
| Power off reset: mechanical limit | |
| Mechanical limit | 2 external adjusting bolts |
| Mechanical specifications | |
| Self locking device | Worm gear and worm mechanism provide self-locking |
| Spring retraction life | 100000 times |
| Output flange | The bottom installation dimension shall conform to ISO5211 international standard |
| Output shaft | The output shaft drive sleeve can be disassembled and machined for adaptability. Can be installed vertically or horizontally |
| Seismic performance | X YZ10g, 0.2~34 Hz, 30 minutes |
| lubrication | Aluminum base grease (EP type) |
| Electrical specifications | |
| Motor power supply | 110/220V AC 1Phase,380/440V AC 3Phase,50/60Hz, ±10% |
| Control power | 110/220V AC 1Phase,50/60 Hz, ±10% |
| Electric machinery | Squirrel cage asynchronous motor, insulation class H |
| Failsafe/Operating Temperature | Built in thermal protection, open/close 120 ℃± 5 ℃ |
| Heater | 30W(220V AC Anti condensation) Optional |
| Cable entry | 2×NPT 3/4″ ,1×NPT 1″ |
| EC Directive | |
| Conformity with EC Directives | The actuator meets the following requirements |
| ·2014/30/EU Electromagnetic Compatibility ·2014/35/EU Low Voltage | |
| The following harmonized standards | |
| ·General emission standard for industrial environment EN 61000-6-44 ·Rotating electrical machine standard EN 60034-1 | |
| ·General anti-interference standard for industrial environment EN 61000-6-4 | |
